Piston Jack HSS102 10,000kg 56mm

Working load limit:10000,00 kg
Max. operating temperature:80,00 °C
Min. operating temperature:-20,00 °C
Explosion protection:No
Material:Steel
Operating pressure:700,00 bar
Operating principle:Single-acting
Retraction type:Spring return
Oil capacity:81,00 cm3
Piston version:Threaded piston
Piston stroke:56,00 mm
Cylinder height retracted:131,00 mm
Cylinder piston diameter:35,00 mm
Effective piston surface:14.4 cm2
Cylinder diameter:57,00 mm
Collar thread of cylinder body:"2 1/4""-14-UN"
Pressure piece type:Fixed
Safety valve against overpr.:No
Integrated pump:No
Outside mounting thread:M 8
Colour:red
Locking ring:No
Product description:Piston Jack
Manufacturer:Hi-Force
Brand:Hi-Force
Short text product descr.:Lifting Cyl.
Type designation:HSS102]]>
