Working load limit:10000.00 kg Max. operating temperature:80.00 °C Min. operating temperature:-20.00 °C Explosion protection:No Material:Steel Operating pressure:700.00 bar Operating principle:Single-acting Retraction type:Load return Oil capacity:9 cm3 Piston version:Smooth piston Piston stroke:6 mm Cylinder height retracted:28.00 mm Cylinder piston diameter:38.00 mm Effective piston surface:14.4 cm2 Cylinder diameter:87.00 mm Pressure piece type:Fixed Safety valve against overpr.:No Integrated pump:No Colour:red Locking ring:No Product description:Piston Jack Manufacturer:Hi-Force Brand:Hi-Force Short text product descr.:Lifting Cyl. Type designation:HVL10]]>
